ASRock ALiveNF4G-DVI
Płyty w formacie MiniATX cieszą się coraz większym zainteresowaniem i coraz więcej firm ma je w swojej ofercie. Wyposażone w pasywne układy chłodzenia, wyposażone w zintegrowane karty graficzne stanowią doskonałą platformę dla domowej rozrywki. ASRock ALiveNF4G-DVI zbudowano na chipsetach nVidia nForce 410 MCP i GeForce 6100 (wyjścia DVI-D, D-Sub). Na płycie znajdziemy : 4 banki pamięci, slot PCIexpres x16, 2 x PCI i 1 x PCIexpres x1, 4 porty SATA II, 2 x EIDE, dźwiękówkę 7.1 i kartę sieciową FastEthernet. Ceny nie podano.
CPU- Socket AM2 for AMD Athlon™ 64FX / 64X2 / 64 and Sempron Processors
- AMD LIVE!™ Ready
- Supports AMD's Cool 'n' Quiet Technology
- FSB 1000 MHz (2.0 GT/s)
- Supports Untied Overclocking Technology
- Supports Hyper-Transport TechnologyChipset- Northbridge: NVIDIA® GeForce 6100
- Southbridge: NVIDIA® nForce 410 MCPHybrid Booster- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)Memory- Dual Channel DDRII memory technology
- 4 x DDRII DIMM slots
- Supports DDRII800/667/533
- Max. capacity: 8GBExpansion Slot- 2 x PCI slots
- 1 x PCI Express x16 slot
- 1 x PCI Express x1 slotGraphics- Integrated NV44 graphics DX9.0 VGA
- Pixel Shader 3.0
- Max. shared memory 128MB
- Dual VGA Output: Support DVI-D and D-Sub ports by independent display controllers
- NVIDIA® PureVideo™ ReadyAudio- Realtek ALC888 7.1 channel CODEC with High Definition Audio LAN- Realtek PHY RTL8201CL
- Speed: 10/100 Ethernet
- Supports Wake-On-LANConnector- 2 x Serial ATAII 3.0 Gb/s connectors, support RAID (RAID 0, RAID 1, JBOD) and "Hot Plug" functions
- 2 x ATA133 IDE connectors (support 4 x IDE devices)
- 1 x Floppy connector
- 1 x IR header
- 1 x Game header
- 1 x COM Port header
- 1 x HDMI_SPDIF header
- CPU/Chassis FAN connector
- 20 pin ATX power connector
- 4 pin 12V power connector
- CD in header
- Front panel audio connector
- 3 x USB 2.0 headers (support 6 USB 2.0 ports)Rear Panel I/OASRock DVI I/O
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x VGA/D-Sub Port
- 1 x VGA/DVI-D Port
- 1 x Parallel Port (ECP/EPP Support)
- 4 x Ready-to-Use USB 2.0 Ports (including 2 ports on bundled USB+COM port bracket)
- 1 x RJ-45 Port
- HD Audio Jack: Side Speaker / Rear Speaker / Central / Bass / Line in / Front Speaker / MicrophoneBIOS Feature- 4Mb AMI BIOS
- AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 SupportSupport CD- Drivers, Utilities, AntiVirus Software (Trial Version)Hardware Monitor- CPU Internal Temperature Sensing
- CPU Ambient Temperature Sensing
- Chassis Temperature Sensing
- CPU Fan Tachometer
- Chassis Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, VcoreAccessories- Quick Installation Guide, Support CD, I/O Shield
- Floppy/ATA 133 cables
- 1 x SATA data cable (optional)
- 1 x SATA 1 to 1 power cable (optional)
- 1 x USB+COM port bracket (optional)
- 1 x HDMI_SPDIF cable (optional)Form Factor- Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cmOS- Microsoft® Windows® 2000 / XP / XP Media Center / XP 64-bit / Vista™ compliant Certifications- FCC, CE, WHQL
